| MODEL | Bearing Type | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Acoustic Noise | Life expectancy | |||
| PART NO. | SIGNAL |
B.T.S.R |
VDC |
VDC |
Amp |
Watt |
R.P.M. |
m³/min |
CFM |
mmH₂O |
IN H₂O |
dB-A |
hours |
| DFPF0656_2U | -FG / RD | B | 12 | 10.8 to 13.2 | 3.10 | 37.2 | 18300 | 2.273 | 80.20 | 115.80 | 4.559 | 73.0 | 70000 |
| Product P&Q Curve Dimension Drawing | |||||||||||||
|
|
|||||||||||||
